- Material: 100% 4130 CrMo
- Heat-treated, internal top tube and external down tube gusset, butted tubing, tapered rear triangle
Geometry:
- Chainstay length (CS): 13.25" (33.65cm) - 13.7" (34.79cm)
- Head tube angle (HA): 75.5°
- Seat tube angle (SA): 71°
- Bottom bracket height: 11.625" (29.53cm)
- Frame height (SO): 9" (22.86cm)
Seat clamp: Integrated
Seatpost diameter: 25.4mm
Bottom bracket: Mid BB
Dropouts: Investment cast, 8mm thick, 14mm axle slot
Chain tensioner: Integrated
Brake type: U-brake
Brake mounts: Screw-on
Extras: Brake mounts not included Delivery included
